19
15. Technical Specifications
Max dimension, CPE
W x H x D = 158x143x60mm
Max dimension, Giftbox
W x H x D = 170x152x100mm
Weight, Giftbox
0.52kg
Operating voltage
See the supplied power adapter
Operating frequency
See the supplied power adapter
Temperature
Operating
0°C to 40°C
32°F to 104°F
Non-operating:
-20°C to 60°C
-4°F to 140°F
Humidity (relative, non-
condensing)
Operating
10% to 90%,
Non-operating
5% to 95%
Frequency Band
According to Directive 2014/53/EU
Maximum Radio-Frequency Power (EIRP)
According to Directive 2014/53/EU
WiFi 2412 2472MHz
WiFi 5150 5250MHz
WiFi 5250 5350MHz
WiFi 5470 5725MHz
WiFi 100mW
WiFi 200mW
WiFi 100mW
WiFi 200mW
This device is restricted to indoor use when operating in the 5150 MHz - 5350 MHz frequency
range in following countries.
BE
EL
LT
PT
BG
ES
LU
RO
CZ
FR
HU
SI
DK
HR
MT
SK
DE
IT
NL
FI
EE
CY
AT
SE
IE
LV
PL
UK
