CHAPTER 13: ANTI-TIPS
USER-FRIENDLY ANTI-TIPS
Engaging
To engage the User-Friendly Anti-Tip, grip the anti-tip rmly, pressing down on the release lever, lower the anti-tip
until the anti-tip receiver re-engages in the anti-tip mount in the “down” position shown in Figure 13-3.
Figure 13-3
Engaging the Anti-Tip
Anti-Tip
Mount
Release
Lever
Receiver
Disengaging
To disengage the User-Friendly Anti-Tip, grip the anti-tip rmly, pressing down on the release lever, raise the anti-tip
until the anti-tip receiver re-engages in the anti-tip mount in the “up” position shown in Figure 13-4.
Figure 13-4
Disengaging the Anti-Tip
