Alpha Black Elite - Parts List
Item
Part
Number
QTY Description
98-37N
1
Safety Assembly
22 TR02058 1 Safety Pin
23 FA-07 1 O-Ring, BUNA, 70A, 2-006, Black
24 98-55 1 O-Ring, BUNA, 70A, 2-006, Red
25 TA06004 1 Trigger
26 98-19 2 Dowel Pin 0.125" X 0.250"
27 98-20 2 Spring, Comp., 0.425" F.L., x 0.180" O.D.
28 98-18 1 Trigger Return Slide
29 02-35 1 Sear
30 02-20 1 Comp. Spring, 0.600"Fl X 0.172"O.D.
31 98-15 1 Dowel Pin 1/8" X 1/2"
32 98-44 1 Front Sight Spring
33 98-14 1 Feed Elbow Latch
34 FA-18 1 Ball Latch
35 CA-08B 2 Nut, 10-32 Square MS
36 TA06039 1 Receiver - Left Side
37 98-01A 3 Screw, LHSHCS
38 TA06015 3 Screw, LHSHCS 10-32 X 0.840"
39 PL-01A 1 Screw, BHCS 10-32 X .875"
40 98-06A 1 Screw, BHCS 10-32 X 1.125"
98-E 1
Feed Elbow Assembly
41 98-04 1 Feed Elbow
42 TA02076 2 Dowel Pin, Knurled
43 98-43 1 Feed Elbow Latch
44 TA05052 2 Screw, Phil Truss
45 PL-42C 1 Screw, SHCS 1/4-20 X 1.0"
46 98-45 1 Washer, M6
47 PL-42D 1 Nut,Square 1/4-20
48 TA05004 1 Receiver Grip, Right Side
49 CA-02A 4 Screw, BHCS
50 TA06003 1 Receiver Grip, Left Side
51 TA06078 1 Barrel
52 TA09919 1 Bolt, LHSHCS, 10-32 X 0.5”
