Alpha Black Elite - Parts List
Item
Part
Number
QTY Description
Shaded items are assemblies.
You may order the assembly part number or individual parts that make up the assembly.
1 TA06040 1 Receiver - Right Side
2 9-PA 6 Hex Nut, Black
3 98-21NR 1 Power Tube
4 02-22 1 Velocity Screw, 5/16-24 x 7/16"
5 98-V 1
98 Valve Assembly
A 98-12A 1 O-Ring, C.U., 90A, 2-019
B 98-56 1 Valve Plug
C SL2-25 2 O-Ring, C.U., 70A, 2-012
D 98-32 1 Comp. Spring, 0.983"Fl X 0.404"O.D.
E CA-27 1 Valve Seat
F PA-31A 1 Snap Ring, Internal
G 98-PL 1 Valve Plunger
6 98-09N 1 Gas Line
7 98-06 1 Air Supply Adapter (ASA)
8 98-26 2 Screw, BHCS
9 TA02011 1 Rear Bolt
10 98-12A 1 O-Ring, C.U., 90A, 2-019
11 TA05005 1 Rear Bolt Plug
12 98-13 1 Rear Bolt Handle
13 CA-14 1 Spring, Comp., 4.392" F.L., x 0.189" O.D.
14 CA-15 1 Pin, Flt. Fillister Hd
15 98-40 2 O-Ring, 2-117
16 TA01016 1 Linkage Arm
17 02-17 1 Front Bolt
18 SL2-4 1 O-Ring, BUNA, 70A, 2-015
19 TA06006 1 End Cap
20 98-33 4 Dowel Pin
21 CA-36 1 Dowel Pin
65 TA02021 2 Linkage Arm Pin
