Getting Started
• Eyeprotectiondesignedforpaintballusemustbewornbytheuserandanyperson
withinrange.
• Donotdisassemblethismarkerwhileitispressurized.
• Donotpressurizeapartiallyassembledmarker.
• Readeachstepcompletelybeforeperformingthestep.
NOTE:Carefullyhandstartallthreadedpartswhenassembling,anddonotovertighten,as
thismaypotentiallystripthethreadedparts.RefertotheParts Diagramonpages20and21
fortheseinstructions(itemnumbersareinparentheses).
1. Install the Barrel
a. Makesurethe
BarrelO-Ring(15)
isinplaceonthe
endoftheBarrel.
b. SlidetheBarrel
throughtheShroudandturnitclockwisetothreaditintotheReceiver.
2. Install the Components to the Marker
Collapsible Stock
a. Finda10-32x1/2”blackscrew(B)inthe
MaintenancePack.
b. InserttheStockintotheslotsontheEndCapof
themarker(A).
c. Insertandtightenthescrew(B).
Length Adjustment
1. SqueezetheAdjustmentLever.
2. SlidetheStocktogetheroraparttothe
desiredlength.
3. ReleasetheAdjustmentLever.
Feed Elbow
a. RefertoFigures12and14onpages
16-17beforeattemptingtoinstallthe
FeedElbow.AligntheFeedElbowpinswiththetwobossesontherightsideofthe
marker.
b. Insertthepinsintothebosses.
c. TipupuntiltheFeedElbowlocksintoplace.
WARNING
Install the air supply and load the hopper with paintballs only after you:
• have a barrel blocking device installed (see page 4)
• have the Trigger Safety in Safe mode (see page 6).
Eye protection designed for paintball use must be worn by the user
and any person within range.
a
B
2
1
3
Figure 2: Install and Adjust Stock
Figure 1: Install the Barrel.
51
15
