G = Use Tippmann grease on items
6, 7, and 47 every 8 - 10,000 shots.
For items 7 and 47, be sure to apply
grease to the inside bore as well as
the outside of the part.
Figura 12: X7 Phenom Sub-assemblies
16
18
19
13
12
15
22
67
11
47
7
6
20
19
12
17
14
3
5
4
13
9
1
2
WARNING
Do not disassemble this marker
while it is pressurized.
Do not pressurize a partially
assembled marker.
