Titan Performance Series 450e User Manual

Performance Series 450e 21
Item Part No. Description
1 0558 302 Motor shroud
2 9805 287 Screw(4)
3 0558 555 Powercordjumper*
4 0551 714 Cord grip
5 9805 259 Ground screw
6 0509 218 Screw(4)
7 0523 527A Motor control assembly
8 0507 751 Grommit
9 0509 550 Screw(4)
10 03662 Microswitch insulator
11 0522 362 Microswitch
12 9800 604 Screw(2)
13 0509 219 Screw
14 0551 513 Knob
15 0551 522 Knobhousing
16 9822 522 Retaining ring
17 02712 Spring
18 0551 521 Plunger
19 -------- Drive assembly
Item Part No. Description
20 0509 218 Screw(4)
21 0558 301 Face plate
22 0558 263A Fluid section assembly
23 0507 931 Cam base
24 5006 543 Groove pin
25 0507 662 Relief valve knob
26 730-197 Cap
27 9885 612 Returntubetting
28 0508 553 Screw(2)
29 0508 239 Manometer
30 0551 705 Siphon assembly
31 ------- Powercord(seeinset,left)
32 0551 714 Cordgrip*
33 0509 218 Screw(6)*
34 9800 340 Groundscrew(2)*
35 0558 452 Bracketcover*
36 0558 449 Bracket*
37 0551 980 Locknut(2)*
38 0522 424 EMIlter,20A*
 * UKonly
