Performance Series 450e 25
Spare parts list
Performance Series 450e
1
2
3
7
6
4
5
Motor Assembly
Item Part No. Description
1 0522 100 Capacitor assembly
2 806-304 Fanshroud(2)
3 704-322 Screw(2)
4 806-308 Fan
5 9804 916 Screw
6 0551 543 Tie wrap
7 0551 540 Motor,LabyrinthKitassembly,120V
