Titan Performance Series 450e User Manual

Performance Series 450e 23
Item Part No. Description
1 0509 594 Retainer
2 0509 584 Piston guide
3 ------- Upperpacking
4 0551 535 Spacer
5 0551 112 Transducer assembly
6 806-106 Pump manifold
7 0509 873 Fitting
8 0507 690 Bypass valve assembly
9 0507 745 Gasket
10 ------- Lowerpacking(2)
11 0290 277A Piston rod
12 806-309 Uppercage
13 0551 263 Crush washer
14 0516 303 Outlet valve ball
15 0551 620 Outlet valve seat
16 13481 Outlet valve retainer
17 704-535 Bushing
18 0509 581 Inlet valve seal
19 0509 591 Lower ball guide
20 0509 583 Inlet valve ball
21 0551 534 Inlet valve seat
22 0509 582 O-ring,Teon
23 0508 680 Inlet valve housing
24 0516 775 Filter housing
25 0515 252 Filter
26 0296 289 O-ring
27 0507 517 Pipe plug
0509 151 Piston assembly
(includesitems11-16)
0551 533 Repackingkit(includes
items 2-4, 10, 12, 14, 18,
20and22).
