English
10
Cleanup Using
the Quick-
Flush Lid*
Start
English
You will need:
• A garden hose
• A waste bucket
* Latex materials only
You will need a garden hose to complete
these steps. If you do not have a garden
hose available, or if you used oil-based
materials, follow the Cleanup for Oil-Based
Materials instructions on page 12.
1. Remove the battery pack.
Pour the remaining material
back into the original container.
2. Remove the suction tube. 3. Turn the spray tip counter-
clockwise until it is removed.
Pull out the atomizer valve,
being careful not to lose it.
5. Slide the pump housing
assembly off the sprayer.
Remove the piston and spring
from the pump housing. Place
all removed parts (except the
pump housing) into the material
container (see inset).
4. Using the spray tip, turn the
locking nut counterclockwise
until it is removed.
6. Snap Quick Flush lid into
place on the pump housing
ring as shown.
1
4
2 3
5 6
To Next Page
