Car winches- specification
Colorado series
Winch Colorado 8000 lbs
Rated line pull:
8,000lb (3,630kg)
Motor:
5.0 HP
Geartrain:
3 stage planetary
Gear ratio:
216: 1
Clutch:
FGR
Brake:
Automatic in the motor base
Rope dimension ( mm x m):
8.0mm x 16m
Mounting bolt pattern ( mm x mm):
164mm x 114.3mm
Relay:
2 x 300A
Winch dimension:
453mm x 160mm x 200mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
14.8 (4.5)
80
1/8000 (3630)
2000 (907)
10.5 (3.2)
150
2/6780 (3080)
4000 (1810)
8.2 (2.5)
210
3/5745 (2610)
6000 (2720)
5.9 (1.8)
275
4/4870 (2210)
8000 (3630)
3.9 (1.2)
330
Winch Colorado 9500 lbs
Rated line pull:
9,500lb ( 4,315kgs )
Motor:
5.5 HP
Geartrain:
3 stage planetary
Gear ratio:
216: 1
Clutch:
FGR
Brake:
Automatic in the motor base
Rope dimension ( mm x m):
10mm x 24m
Mounting bolt pattern ( mm x mm):
255mm x 114.3mm
Relay:
2 x 300A
Winch dimension:
540mm x 160mm x 200mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
23.3 (7.1)
75
1/9500 (4315)
2000 (907)
15.1 (4.6)
130
2/7900 (3590)
4000 (1810)
12.8 (3.9)
190
3/6580 (2990)
6000 (2720)
10.2 (3.1)
255
4/5480 (2485)
8000 (3630)
7.2 (2.2)
310
9500 (4315)
4.6 (1.4)
415
