Arctica series
Winch Arctica 3500 lbs
Rated line pull:
3,500lb ( 1,590 kgs )
Motor:
1.7 HP
Geartrain:
3 stage planetary
Gear ratio:
158:1
Clutch:
Automatic
Brake:
Mechanical brake
Rope dimension (mm x m):
5mm x 15m
Mounting bolt pattern (mm x mm):
76mm x 124mm
Relay:
250A
Winch dimension:
330mm x 117mm x 120mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
9.5 (2.9)
25
1/3500 (1590)
1000 (453)
5.9 (1.8)
80
2/2125 (965)
2000 (907)
4.9 (1.5)
130
3/1805 (820)
3000 (1360)
3.6 (1.1)
185
4/1500 (680)
3500 (1590)
2.9 (0.9)
210
Winch Arctica 4500 lbs
Rated line pull:
4,500lb ( 2,040kgs )
Motor:
1.9 HP
Geartrain:
3 stage planetary
Gear ratio:
185:1
Clutch:
Automatic
Brake:
Mechanical brake
Rope dimension (mm x m):
6.5mm x 15m
Mounting bolt pattern (mm x mm):
76mm x 167mm
Relay:
250A
Winch dimension:
420mm x 135mm x 125mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
13.1 (4.0)
30
1/4500 (2040)
1000 (453)
9.2 (2.8)
70
2/3750 (1700)
2000 (907)
7.5 (2.3)
105
3/3175 (1440)
3000 (1360)
5.9 (1.8)
150
4/2730 (1240)
4500 (2040)
2.6 (0.8)
230
