Titanium J8 3000 - ATV Winches- Specification; J7, J8, J9 Series

78
Winch Arctica 13 500 lbs
Rated line pull:
13,500lb ( 6,130kgs )
Motor:
6.6 HP
Geartrain:
3 stage planetary
Gear ratio:
243:1
Clutch:
Type „T”
Brake:
Automatic in the end of the gear box
Rope dimension ( mm x m):
10mm x 24m
Mounting bolt pattern ( mm x mm):
254mm x 114.3mm
Relay:
1 x 450A
Winch dimension:
582mm x 165mm x 240mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
15.7 (4.8)
70
1/13500 (6130)
2000 (907)
10.8 (3.3)
115
2/10900 (4950)
4000 (1810)
9.5 (2.9)
180
3/9100 (4130)
7000 (3180)
7.9 (2.4)
260
4/7600 (3450)
10000 (4540)
5.6 (1.7)
330
13500 (6130)
3.3 (1.0)
430
ATV winches- specification
J7, J8, J9 series
Winch J7 2000 lbs A
Rated line pull:
2,000lb ( 907kgs ) double line
Motor:
0.7 HP
Geartrain:
3 stage planetary
Gear ratio:
153:1
Clutch:
Automatic
Brake:
Mechanical brake
Rope dimension ( mm x m):
5mm x 15m
Mounting bolt pattern ( mm x mm):
76mm x 124mm
Relay:
2x40A
Winch dimension:
280mm x 100mm x 110mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
8.2 (2.5)
12
1/2000 (907)
1000 (453)
5.2 (1.6)
45
2/1695 (770)
1500 (680)
3.6 (1.1)
70
3/1436 (652)
2000 (907)
2.3 (0.7)
90
4/1220 (554)
