79
Winch J7 2000 lbs B
Rated line pull:
2,000lb ( 907kgs ) double line
Motor:
0.7 HP
Geartrain:
3 stage planetary
Gear ratio:
153:1
Clutch:
Automatic
Brake:
Mechanical brake
Rope dimension ( mm x m):
5mm x 15m
Mounting bolt pattern ( mm x mm):
76mm x 124mm
Relay:
2x40A
Winch dimension:
280mm x 100mm x 110mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
8.2 (2.5)
12
1/2000 (907)
1000 (453)
5.2 (1.6)
45
2/1695 (770)
1500 (680)
3.6 (1.1)
70
3/1436 (652)
2000 (907)
2.3 (0.7)
90
4/1220 (554)
Winch J7 2500 lbs
Rated line pull:
2,500lb ( 1,125kgs )
Motor:
1.2 HP
Geartrain:
3 stage planetary
Gear ratio:
153:1
Clutch:
Automatic
Brake:
Mechanical brake
Rope dimension ( mm x m):
5mm x 15m
Mounting bolt pattern ( mm x mm):
76mm x 124mm
Relay:
120A
Winch dimension:
303mm x115mm x110mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
8.2 (2.5)
15
1/2500 (1125)
1000 (453)
5.6 (1.7)
50
2/2270 (1030)
2000 (907)
3.9 (1.2)
105
3/2060 (935)
2500 (1125)
2.6 (0.8)
140
4/1870 (850)
