Titanium J8 3000 - Hunter Series; Arctica Series

77
Hunter series
Winch Hunter 12 000 lbs
Rated line pull:
12,000lb ( 5,450kgs )
Motor:
6.0 HP
Geartrain:
3 stage planetary
Gear ratio:
216: 1
Clutch:
Type „T”
Brake:
Automatic in the end of the gear box
Rope dimension ( mm x m):
10mm x 24m
Mounting bolt pattern ( mm x mm):
254mm x 114.3mm
Relay:
1 x 450A
Winch dimension:
555mm x 155mm x 235mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
21.6 (6.6)
65
1/12000 (5450)
2000 (907)
12.5 (3.8)
125
2/9800 (4450)
4000 (1810)
9.5 (2.9)
195
3/8300 (3770)
6000 (2720)
8.5 (2.6)
250
4/7200 (3270)
8000 (3630)
7.2 (2.2)
310
10000 (4540)
5.6 (1.7)
370
12000 (5450)
4.6 (1.4)
420
Arctica series
Winch Arctica 12 000 lbs
Rated line pull:
12,000lb ( 5,450kgs )
Motor:
6,6 HP
Geartrain:
3 stage planetary
Gear ratio:
172:1
Clutch:
Type „T”
Brake:
Automatic in the end of the gear box
Rope dimension ( mm x m):
10mm x 24m
Mounting bolt pattern ( mm x mm):
254mm x 114.3mm
Relay:
1 x 450A
Winch dimension:
582mm x 165mm x 240mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
21.0 (6.4)
75
1/12000 (5450)
2000 (907)
11.2 (3.4)
150
2/9800 (4450)
4000 (1810)
9.5 (2.9)
195
3/8300 (3770)
6000 (2720)
8.2 (2.5)
270
4/7200 (3270)
8000 (3630)
6.2 (1.9)
325
10000 (4540)
4.6 (1.4)
380
12000 (5450)
3.9 (1.2)
430
