76
Winch Renegade 13 500 lbs
Rated line pull:
13,500lb ( 6,130 kg )
Motor:
6.2 HP
Geartrain:
3 stage planetary
Gear ratio:
265: 1
Clutch:
FGR
Brake:
Automatic in the motor base
Rope dimension ( mm x m):
10mm x 24m
Mounting bolt pattern ( mm x mm):
255mm x 114.3mm
Relay:
1 x 450A
Winch dimension:
574mm x 200mm x 265mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
17.7 (5.4)
65
1/13500 (6130)
2000 (907)
9.5 (2.9)
130
2/10900 (4950)
4000 (1810)
8.2 (2.5)
205
3/9100 (4130)
6000 (2720)
7.2 (2.2)
260
4/7600 (3450)
8000 (3630)
5.9 (1.8)
330
10000 (4540)
4.3 (1.3)
390
13500 (6130)
3.0 (0.9)
440
Winch Renegade 17 000 lbs
Rated line pull:
17,000lb ( 7,710kgs )
Motor:
6.6 HP
Geartrain:
3 stage planetary
Gear ratio:
360:1
Clutch:
Type „T”
Brake:
Automatic in the motor base
Rope dimension ( mm x m):
12 mm x 24m
Mounting bolt pattern ( mm x mm):
255mm x 114.3mm
Relay:
1 x 450A
Winch dimension:
587mm x 210mm x 260mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
13.8 (4.2)
70
1/17000 (7710)
2000 (907)
9.5 (2.9)
115
2/14160 (6430)
8000 (3630)
6.6 (2.0)
160
3/11800 (5360)
12000 (5450)
4.6 (1.4)
230
4/9830 (4465)
15000 (6810)
3.3 (1.0)
380
17000 (7710)
2.3 (0.7)
430
