Winch Renegade 12 000 lbs
Rated line pull:
12,000lb ( 5,450kgs )
Motor:
6.0 HP
Geartrain:
3 stage planetary
Gear ratio:
265: 1
Clutch:
FGR
Brake:
Automatic in the motor base
Rope dimension ( mm x m):
10mm x 24m
Mounting bolt pattern ( mm x mm):
255mm x 114.3mm
Relay:
1 x 450A
Winch dimension:
540mm x 160mm x 160mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
18.0 (5.5)
65
1/12000 (5450)
2000 (907)
10.5 (3.2)
130
2/9800 (4450)
4000 (1810)
8.2 (2.5)
205
3/8300 (3770)
6000 (2720)
6.9 (2.1)
260
4/7200 (3270)
8000 (3630)
5.9 (1.8)
320
10000 (4540)
4.9 (1.5)
380
12000 (5450)
3.9 (1.2)
430
Winch Monster Renegade 12 000 lbs
Rated line pull:
12,000lb ( 5,450kgs )
Motor:
6.0 HP
Geartrain:
3 stage planetary
Gear ratio:
216: 1
Clutch:
FGR
Brake:
Automatic in the motor base
Rope dimension ( mm x m):
10mm x 24m
Mounting bolt pattern ( mm x mm):
255mm x 114.3mm
Relay:
1 x 450A
Winch dimension:
535mm x 160mm x 280mm
Line pull
Line speed
Motor
Pull by layer
LBS (KG)
FT/min (M/min)
Motor current (A)
Layer/Lbs(Kg)
0
21.6 (6.6)
65
1/12000 (5450)
2000 (907)
12.8 (3.9)
125
2/9800 (4450)
4000 (1810)
9.2 (2.8)
195
3/8300 (3770)
6000 (2720)
8.2 (2.5)
250
4/7200 (3270)
8000 (3630)
6.9 (2.1)
310
10000 (4540)
5.2 (1.6)
370
12000 (5450)
4.9 (1.3)
420
