41
In the menu, an Orion corresponds to an Orbit-2 (Profi DP reader*2).
In the following example, option 2, Profi DP reader-2, has been selected:
--- Device functionality test ---
Enter the device to test 1..8) : 1
1) Profi DP reader-1
2) Profi DP reader-2
3) Profi DP io
Enter the device type : Profi DP reader-2
Enter slave no. 1)..4) (CR=1): 1
MT interface or Wiegand interface [M/W] for reader 1 ? : M
MT interface or Wiegand interface [M/W] for reader 2 ? : M
Continue [Y] ? :
Screen 3: Device functionality test
On this screen, entry of the slave number is requested. This value must be set to 1.
The right type of interface must be chosen for both reader inputs.
Once all entries have been confirmed as correct, the options and mode relevant to the selected
device are displayed:
--- Profibus DP orbit reader test, no. 2 ---
Label Orion
1) Output R1-0: On : (H1)
2) Output R1-1: On : (O2)
3) Output R2-0: On : (H2)
4) Output R2-1: On : (O5)
5) RdrLED R1
6) RdrLED R2
Input R1-0: Off 128 : (A1)
Input R1-1: Off 128 : (A2)
Input R1-2: Off 128 : (A3)
Input R1-3: Off 128 : (T1)
Input R2-0: Off 128 : (A4)
Input R2-1: Off 128 : (A5)
Input R2-2: Off 128 : (A6)
Input R2-3: Off 128 : (T2)
Reader : R1: 29748424 08
State : Data exch.
1)... : toggle output state or flash reader LED S) : stop
Screen 4: Device functionality test, options and mode of an Orion as an Orbit reader
On the above screen, the inputs and outputs can be tested. The outputs can be activated or
deactivated using keys 1 to 4. Keys 5 or 6 can be used to test the card reader LEDs (rapidly
press 5 times to turn on or off).
When a card is presented to one of the card readers, the relevant card information will be
displayed after the Reader field. Here, R1 indicates that card reader 1 has read a card. R2
indicates that card reader 2 has read a card. The number after the scanned card number (08 in
this instance) indicates the number of characters in the card number.
