TOHATSU BFT 90A - Page 71

69
PRE-OPERATION CHECKS
(H2 type)
HANDLE ANGLE: 7°
HANDLE ANGLE: 13°
HANDLE ANGLE:
21°
Install the height adjustment block
so that the selected angle of the
tiller handle is in this position.
HEIGHT ADJUSTMENT
BLOCK
8 × 28 mm
FLANGE BOLT
HEIGHT
Reference point
HANDLE ANGLE: 7°
317 mm
(12.5 in)
378 mm
(14.9 in)
456 mm
(18.0 in)
HANDLE ANGLE: 13°
HANDLE ANGLE: 21°
