89
STARTING THE ENGINE
Emergency Starting
If the starting system does not operate
properly for some reasons, the engine
can be started using the emergency
starter rope in the tool kit.
1. Turn the engine switch key to the
OFF position.
2. Raise the front and rear fixing
levers, and remove the engine
cover.
3. Release the breather tube from the
four clamps.
4. Remove 6 × 25 mm flange bolt and
washer, then remove the ACG
cover.
5. Secure the breather tube to the
clamp of the silencer case.
Take care not to lose the bolt and
washer.
ENGINE COVER FIXING LEVER
(front/rear)
6 mm WASHER
6 × 25 mm
FLANGE BOLT
ACG COVER
CLAMPS
CLAMP
HOOKS
BREATHER TUBE
CLAMP
(on the silencer case)
36ZZ0T030_EN.book Page 89 Tuesday, November 28, 2017 4:19 PM
