2016 Installation Manual
Preparation
1. Remove bolt 1 and remote cont. cable stay
cover
2.
2. Remove bolt
4 and cable clip 5.
3. Remove cable grommet
6.
Multi-function Tiller Handle
installation
1. Install stud bolt 1.
3. Insert main harness
4 from tiller handle, shift
cable
5 and throttle cable 6.
Nylon nut
27 N · m (20 lb·ft) [2.7 kgf·m]
Remove air silencer 3 to remove
remote control cover.
6
1
5
2
3
4
1
1
3
2
6
5
4
Use double nut to install stud bolt.
2. Install Multi-function tiller handle Assy 2, nylon
nut and washer (2pcs.)
3.
Stud bolt
27 N · m (20 lb·ft) [2.7 kgf·m]
