REMOVING AND CARRYING THE OUTBOARD MOTOR34
6
When taking the motor from package or
removing the motor from the boat, never
release the lock lever. If the lock lever is
released, it will be very easy the clamp
bracket to spring up to the tilting direction
because it is not fixed.
* Tie the clamp bracket to the outboard
with a rope.
* Pay attention to the tilting direction so as
not to be injured by the springing clamp
bracket.
Do not go under outboard motor tilted up
even if it is supported by support bar, or
accidental fall of outboard motor could
lead to severe personal injury.
Close air vent screw of fuel tank and fuel
cock before carrying or storing outboard
motor and fuel tank, or fuel may leak,
potentially catching fire.
Tilting direction
Rope
Reverse
Lock lever
LOCK
Clamp bracket
