PROPELLER TABLE 57
13
To ensure optimum performance, the propeller should match the boat type and its load.
Use a genuine propeller.
A propeller must be selected so that the engine rpm measured at wide open throttle, while
cruising, is within the recommended range.
50D2 5,150 to 5,850 rpm
50
Mark
Propeller Size (Diameter Pitch)
Inch mm
Heavier Load
Lighter Load
7* 11.4 x 7.1 290 x 180
9 12.1 x 9.0 307 x 229
11 11.6 x 11.0 295 x 279
12 11.4 x 12.0 290 x 305
13 11.1 x 13.0 282 x 330
14 11.1 x 14.0 282 x 356
15 11.0 x 15.0 279 x 381
* shows propeller with four blades.
W50
Mark
Propeller Size (Diameter Pitch)
Inch mm
Heavier Load
Lighter Load
9 12 x 9.0 305 x 229
10 11.5 x 10.0 292 x 254
11 11.5 x 11.0 292 x 279
12 11.6 x 12.0 295 x 305
13 11.5 x 13.0 292 x 330
14 11.4 x 14.0 289 x 355
15 11.0 x 15.0 280 x 381
16.5 10.7 x 16.4 273 x 417
17.5 10.9 x 17.6 276 x 447
PROPELLER TABLE
