54
Model
Torque Range
N.m kgf.cm kgf.m lbf.in lbf.ft
snug Min Max 1digit sung Min Max 1digit sung Min Max 1digit sung Min Max 1digit sung Min Max 1digit
CTA50N2X12D-G 2.5 10 50 0.05 25 100 500 0.5 0.25 1 5 0.005 22.5 100 450 0.5 1.85 7.5 36.5 0.05
CTA100N2X15D-G 5 20 100 0.1 50 200 1000 1 0.5 2 10 0.01 45 200 900 1 3.8 15 75 0.1
CTA200N2X19D-G 10 40 200 0.2 100 400 2000 2 1 4 20 0.02 88
350
1750 2 7.5 30 150 0.2
CTA360N2X22D-G 18 72 360 0.4 180 720 3600 4 1.8 7 36 0.05 159
640
3150 5 13 52 260 0.5
CTA500N2X22D-G 25 100 500 0.5 250 1000 5000 5 2.5 10 50 0.05 220
880
4400 5 18 72 360 0.5
CTA850N2X32D-G 43 170 850 1 - - - - 4.3 17 85 0.1 - - - - 31 124 620 1
Model
Angle Measuring
Range
Angle
Accuracy
Overall
Length
[mm]
Weight
[kg]
Interchangeable
Head
Min.-Max. 1 digit
CTA50N2X12D-G
0-999° 1°
±2°+1digit
(Angular velocity
is 30°/x~180°/s
when the bolt
turned to 90°)
282 0.58 QH12D
CTA100N2X15D-G 384 0.63 QH15D
CTA200N2X19D-G 475 0.78 QH19D
CTA360N2X22D-G 713 1.13
QH22D
CTA500N2X22D-G 949 4
CTA850N2X32D-G 1387 5.14 QH32D
