8. Various settings (using the key operation on CTA2-G)
CTA2-G requires mode/parameter setting according to customer usage.
Setting can be done through the enclosed application software (refer to its operation manual)
or the key operation on CTA2-G itself.
Single-spindle tightening mode
1. Setting items
Setting items Display
Default
Alternative selection
1 Tightening torque ＳＥＬ MODE-S,MODE-P
2 Measurement Unit USEL N・m kgf・cm/kgf・m/lbf・in/lbf・ft
3 Snug torque Ｓｎｇ
0
Below max torque
4 Tightening angle Ａｎ
0
Below 999
5 Tightening angle upper limit ＡＮ_Ｈ
0
Below 999
6 Tightening direction ｔＵｒｎ
CW
CCW
7 Auto memory/reset timer Ａｒ
0
0.0、0.1～5.0
8 Buzzer ｂＵ
ON
OFF
9 Auto power off ＰｏＦＦ
3min
10min,30min,NONE
10 External output mode ｄｏ
PC
PRN
11 Baud rate ｂｐＳ
9600
2400, 4800, 19200
12 Data length ｄＬ
8bit
7bit
13 Parity Ｐｒｔ
Even
None, Odd
14 Default ｄＦＬｔ
DFLT-N
DFLT-Y
15 Time (h/m/s) ｒｔＣ１ ―――
16 Date (y/m/d) ｒｔＣ２ ―――
* Tightening mode and date/time will not be initialized even with the 13 Default setting.
* Production tightening mode (P37）
* For setting though the application software (PC), refer to the instruction manual enclosed inside
the application CD.
2. Setting by the key operation on CTA2-G (Single-spindle tightening mode).
● RUN mode
Press MD key for more than 2 sec. After the display changes to tightening mode setting, release
the key.
* If it is in production tightening mode, you must press the reset switch or unplug/plug the
