Tohnichi DOTE4-G User Manual

8
DIGITAL TORQUE WRENCH TESTER DOTE4-G
6.
Various Settings
6-1. Setting items
Item
Counter
Upper limit Value
Display
Upper/Lower-limit
Value Selecon/
Lower-limit Value
Display
Main Display
Factory Default Selectable range
1
Seng item selecon - - torq-S PArA-S
2 Measurement unit Unit N·m 4 units
3 A Upper-limit value HI SEt-A 0 0 to Maximum Range
4 A Lower-limit value Lo SEt-A 0 0 to Maximum Range
5 B Upper-limit value HI SEt-b 0 0 to Maximum Range
6 B Lower-limit value Lo SEt-b 0 0 to Maximum Range
7 C Upper-limit value HI SEt-C 0 0 to Maximum Range
8 C Lower-limit value Lo SEt-C 0 0 to Maximum Range
9 D Upper-limit value HI SEt-d 0 0 to Maximum Range
10 D Lower-limit value Lo SEt-d 0 0 to Maximum Range
11 E Upper-limit value HI SEt-E 0 0 to Maximum Range
12 E Lower-limit value Lo SEt-E 0 0 to Maximum Range
13 F Upper-limit value HI SEt-F 0 0 to Maximum Range
14 F Lower-limit value Lo SEt-F 0 0 to Maximum Range
15 G Upper-limit value HI SEt-g 0 0 to Maximum Range
16 G Lower-limit value Lo SEt-g 0 0 to Maximum Range
17 H Upper-limit value HI SEt-H 0 0 to Maximum Range
18 H Lower-limit value Lo SEt-H 0 0 to Maximum Range
19 I Upper-limit value HI SEt-I 0 0 to Maximum Range
20 I Lower-limit value Lo SEt-I 0 0 to Maximum Range
21 J Upper-limit value HI SEt-J 0 0 to Maximum Range
22 J Lower-limit value Lo SEt-J 0 0 to Maximum Range
Item
Counter/Up
-
per-limit Value
Display
Main Display
Factory Default Selecon item
1
Auto memory/reset Ar 0
0.1/0.2/0.3/0.4/0.5/1.0/2.0/3.0/4.0/5.0
2
Key operaon sound bU on oFF
3
External output doUt PC Prn
4
Baud rate bPS 115200 19200/9600/4800/2400
5
Data length LngtH 8bit 7bit
6
Parity PArty nonE odd/EVEn
7
Memory mode dCnt 1000 99
8
Default dFLt dFLt-n dFLt-y
