DIGITAL TORQUE WRENCH TESTER DOTE4-G
1.
Features
2.
Components
3.
Specifications
Model DOTE4-G is a digital torque wrench tester designed for calibrating or adjusting torque
wrenches, and it has the following features:
• No need of torque wrench weight correction. The torque wrench to be measured is set horizontally,
and weight adjustment is not necessary.
• Up to 1000 readings can be stored. The sampling number, maximum value, minimum value
and average value of stored data can be displayed.
• Units of measure include Newton cN.m/N.m, Metric kgf.cm/kgf.m and American lbf.in/lbf.ft.
• The RS232C output terminal and USB, B-type output connectors allow the DOTE4-G to be interfaced to
PC or Tohnichi printer.
• CE marking acquired. The DOTE4-G can be safely used in the EU.
• Main Unit
• AC Adapter, BA-6
• Loading Plate
• Pole Assembly
DOTE20N4-G unit has 2 sets
• Adapter Set
• Operating Instruction
3-1. Common Specication
Display
Count Value
Display Value
Allow Mark Indication
Output
Power Source
AC Adapter Power Source
Environmental Conditions
Accuracy
LED height 11mm
4 gures
6 gures
RUN, Run Mode
PEAK, Peak Mode
M.R, Manual Memory/Reset
A.R, Auto Memory/Reset
Unit, cN.m/N.m/kgf.cm/kgf.m/lbf.in/lbf.ft
Compliant with RS232C
USB, B-type output connector for serial communication
DC12V 1A
AC100 to 240V +/-10%, 50/60Hz
0 to 40 degree C
Humidity below 85% RH, no condensation
+/-1%+1digit
