DIGITAL TORQUE WRENCH TESTER DOTE4-G
5.
Functions and Settings
5-1. RUN Mode, Continuous Value Display
Torque value on display increases by loading torque and returns to 0 when load is released.
RUN mode is mainly used for measuring direct reading type torque wrench. Press “MD” key to change
between RUN and PEAK mode. ▼on RUN is RUN mode condition.
5-2. PEAK Mode, Maximum Value Display
Torque value on display increases by loading torque, and will keep the maximum torque on the display
even after releasing the load. PEAK mode is mainly used for measuring click type torque wrench.
Press “MD” key to change between RUN and PEAK mode. ▼on PEAK is PEAK mode condition.
5-3. Upper/Lower Limit Value Selection
#1 Press “MD” key for two seconds.
#2 Using ▼ or ▲ key, select registered Upper-/Lower-limit values.
#3 Press “STAT” key to select, and back to measurement mode. Press “MD” key for cancellation.
For registration of the upper- and lower-limit values, refer “Section #6. Various Settings”.
5-4. OK/NG Judgment and Data Memory
When press “Memory/Reset" button or Auto Memory/Reset function is acting, OK/NG Judgment is
performed. OK result is displayed in blue color for 0.5 second, and NG in red for one second.
Results are stored up to 1,000.
Decision Criteria HI: Registered upper limit value < Result torque value
OK : Lower limit value
≦
Result torque value
≦
Upper limit value
LO : Result torque value < Registered lower limit value
5-5. Auto Memory/Reset
When load is released, peak torque value will be displayed for between 0.1 to 5.0 seconds.
Value will then be stored and display will return to zero for the next operation.
5-6. Deletion of Data
#1 Delete one data:
Use ▼/▲ keys to show data for deletion, and press “C” key. The data is deleted.
#2 Delete data between two selected results:
Use ▼/▲ keys to select the last result which is to be deleted, then press the “STAT” key to show “Stt”
on display. While “Stt” and count “1” is shown, press ▼ key to show serial number of the selected last
result.
Push ▼/▲ keys to select the serial number which is the beginning result to be deleted, and press “STAT”
key to make a selection.
Total data stored number of the section is shown as “n”. With each push of the “STAT” key, “n”, “HI”, “Lo”
and “Av” is displayed in order. While these statistical number shown on, press “STAT” rst and “C” keys.
The selected data section will be deleted.
#3 Delete all stored data:
Turn on its main switch while pressing the "Memory/Reset" button. “CLEAr” is displayed at the
start-up time, clearing all the data.
Caution: Before delete data, make sure whether or not the data should be deleted.
To Next Page
