3
DIGITAL TORQUE WRENCH TESTER DOTE4-G
3-3. Torque Range and Accessories
Model DOTE20N4-G DOTE50N4-G DOTE100N4-G DOTE200N4-G DOTE500N4-G DOTE1000N4-G
cN·m
Range 200 - 2000 - - - - -
1 Digit 0.2 - - - - -
N·m
Range 2 - 20 5 - 50 10 - 100 20 - 200 50 - 500 100 - 1000
1 Digit 0.002 0.005 0.01 0.02 0.05 0.1
kgf·cm
Range 20 – 200 50 - 500 100 - 1000 200 – 2000 - -
1 Digit 0.02 0.05 0.1 0.2 - -
kgf·m
Range - - - - 5 - 50 10 – 100
1 Digit - - - - 0.005 0.01
lbf·in
Range 18 - 180 44 - 440 88 - 880 170 - 1700 440 - 4400 880 – 8800
1 Digit 0.02 0.05 0.1 0.2 0.5 1
lbf·
Range - 3.6 - 36 7.3 - 73 15 - 150 36 - 360 73 - 730
1 Digit - 0.005 0.01 0.02 0.05 0.1
Max. Eecve Length L’
[mm]
410 660 1100 1650
Inlet Drive [mm]
9.5 12.7 19.0 25.4
Dimension
[mm]
L 506 756 1276 1856
B 339 391 710 775
H 267 269 394
L1 - 805 1195
B1 - 518 666
B2 - 90 150
H1 113 162
H2 171 169 174 238 247
Weight [kg] 12 13 47 49
Accessory
Down
Adapter
DA3-2
277
(Sq.1/2-Inlet
1/4)
DA4-3
- - DA8-6
Hex
Adapter
10-13-19 12-14-17
17-22-27
19-24-30
22-27-29
30-32-36
34-41
46-50
Accuracy +/-1% +1digit
Down Adapter, DA Specicaon
Model Parts#
Dimension [mm]
Allowable
Torque [N·m]
Weight
[g]
Sq. Drive Inlet Drive Height Outside Width
DA3-2 296 9.5 6.35 12 13 14 5
DA4-3 297 12.7 9.5 15 18 70 11
DA6-4 298 19.0 12.7 19 28 220 34
DA8-6 299 25.4 19.0 26 35 750 66
DA12-8 300 38.1 25.4 44 55 2100 320
