DIGITAL TORQUE WRENCH TESTER DOTE4-G
• Continuous printing example for memory mode 1000
• For memory mode 99
“====” denotes that the measured value displayed at the DOTE4-G is either “0” or exceeds 110%.
It is excluded from statistical processing and not printed.
" - " shows in the front of calibrated value for counterclock wise measurement.
The max, min and avarage is calculated by absoluted value.
１：OK SET-A
３０．００ N・m
２：HI SET-A
３１．００ N・m
３：--
= =．= = = N・m
・
・
２０：OK SET-A
３０．００ N・m
------------------
ｎ = １８
Ｈ Ｉ： ３１．００ N・m
LO： ２９．００ N・m
Ｘ ： ３０．００ N･m
Counter: Judgment result, Preset-limit symbol
Torque value, Unit
Torque value for clockewis
Sampling number
Maximum value
Minimum value
Average value
３０．００ N・m-
Torque value for counter clockewise
Judgment OFF: “--”, Preset-limit symbol is Blank
１：３０．００ N・m
２：３１．００ N・m
３：= =．= = N・m
・
・
・
２０：３０．００ N・m
------------------
ｎ = １８
Ｈ Ｉ： ３１．００N・m
LO： ２９．００N・m
Ｘ ： ３０．００N･m
Torque value, Unit
Sampling number
Maximum value
Minimum value
Average value
