3，Mode
Move the cursor to “Mode” and short press [Scroll
Wheel] to modify the work mode, as shown in the figure
below.
Lipo, LiHV, LiFe, and Lion batteries can be charged
and stored.
NiMh, battery and PB battery can choose to
charge. Short press [Scroll Wheel] and [CH/Exit] to take
effect, and return to the previous interface.
4，End voltage（TVC）
Move the cursor to “End Voltage” and short press
[Scroll Wheel] to modify the end voltage of the
single-cell battery. When the working mode is charging,
it is the charging cut-off voltage, and the range is plus or
minus 50mV of the full voltage. When the working mode
is discharge, it is the discharge cut-off voltage. Scroll
[Scroll Wheel] to adjust the value, step 0.01V.
