3. Various Settings
43
3.1.2 Data/Setting Item Display
After moving to the function mode, each time the [ENTER] button is pressed, the type of
data/setting items changes. Press the [ENTER] button until the data/setting item to be
checked or changed is displayed.
The displayed data/setting items are as shown below.
・ The Standard sample and white board are not displayed when measurement of them are not
performed.
When measuring light source color - Dip switch 3 is on the SOURCE side -
・ Standard sample
☞
「3.2 Standard sample」
・ Correction Factor
☞
「3.6 Correction Factor」
・ Area Correction Factor
☞
「3.7 Area Correction Factor」
・ Measurement Range
☞
「3.8 Measurement Range」
・ RS-232C Parameter
☞
「3.9 RS-232C Parameter」
・ Buzzer Sound
☞
「3.10 Buzzer Sound」
・ Communication Format
☞
「3.11 Communication Format」
・ Average Measure
☞
「3.12 Average Measure」
・ Maintenance Recommended Display
☞
「3.13 Maintenance Recommended Display」
When measuring object color - Dip switch 3 is on the OBJECT side -
・ Standard sample
☞
「3.2 Standard sample」
・ White board
☞
「3.3 White Board」
・ White Board Luminance Factor
☞
「3.4 White Board Luminance Factor」
・ White Board Correction Factor
☞
「3.5 White Board Correction Factor」
・ Correction Factor
☞
「3.6 Correction Factor」
・ Measurement Range
☞
「3.8 Measurement Range」
・ RS-232C Parameter
☞
「3.9 RS-232C Parameter」
・ Buzzer Sound
☞
「3.10 Buzzer Sound」
・ Communication Format
☞
「3.11 Communication Format」
・ Average Measure
☞
「3.12 Average Measure」
・ Maintenance Recommended Display
☞
「3.13 Maintenance Recommended Display」
Memo
