Topcon BM-7AC - Remote Measurement Output Format

4. Communication With a PC
71
4.3 Remote Measurement Output Format
During remote measurement (ST command), the output format of data from the instrument is as
shown below.
■BM-7A Series Mode
Row
number
Output data
example
Data Contents
1
D1
Level of luminance of the measured object with respect to the
measurement range of the instrument
0: Normal 1: Under 2: Over
2
TS
Response speed of the photo-receiver circuit
TF: FAST TS: SLOW
3
MA
Measurement range MA: AUTO MM: MANUAL
4
X1
X Range (X1 to X5)
5
Y1
Y Range (Y1 to Y5)
6
Z1
Z Range (Z1 to Z5)
7
UC
Unit UC: cd/㎡
8
F2
Measurement angle F1: 0.1° F2: 0.2° F3: 1.0° F4: 2.0°
9
K2
Correction factor
K0: No correction K1 to K9: Correction factor number
10
FG1
Area correction group number in area correction function
FG0: No correction FG1 to FG10: Area correction group number
11
GK0
Applicable chromaticity area in the area correction function
GK0: No applicable area
GK1 to GK5: Color data corresponding to the area
12
1.234E+56
Luminance
13
1.234E+56
Tristimulus value X
14
1.234E+56
Tristimulus value Y
15
1.234E+56
Tristimulus value Z
16
1.234
Chromaticity x
17
1.234
Chromaticity y
18
1.234
Chromaticity u’
19
1.234
Chromaticity v’
20
12345
Color temperature
21
123456
Deviation
22
END
Data end command
