4
Step View Procedure
2. Fasten the BASE PLATE
(9090-1613) and secure with
the supplied M6 SCREWS
(2506-0119).
3. Secure the CropSpec
SENSORS
(319000101AGA3838) to
the BASE PLATES (9090-
1613), one on each side.
Note: The sensor with the
lower ID value should be
installed on the left side of
the vehicle. The identity
sticker can be found under
the sensor.
For a two-sensor CropSpec
kit (1004326-01), the final
set up has a sensor on each
side of the tractor roof.
