− 31 −
YES
NO
%
YES
YES
YES
NO
NO
NO
The instrument is partly reset
and then is not activated.
There is voltage of
+24V between +24V and GND
in MAIN PCB.
There is voltage of
+24V between +24V and GND
in L PCB.
There is voltage of
+24V between +24V and GND
in R PCB.
Replace the L PCB and R PCB.
!
&
Replace the unit (spherical unit).
*
The cylindrical unit must be
repaired in factory.
%
It does not stop and
keeps rotating.
R-CV5000-0-0704-01
