− 48 −
3-7 Version up of software
3-7-1 Version up of software with personal computer
The version of the CV-5000 instrument ROM must be 1.13 or higher.
The version of the CV power supply unit ROM must be 1.11 or higher.
* Do not connect KB-50 in the sequence of the work.
1. Necessary tools
Personal computer *1
CD of “CV-5000 Install Program by
USB Ver. 1.10” *2
(Mouse)
Phillips screwdriver
Tweezers
USB cable
(A terminal-mini-B terminal)
*1 : OS (Operating System) should be WindowsXP.
: There should be one free USB (1.0 or 2.0) or more.
*2 : The contents of the distributed CD are shown below.
CV5000 folder
├
1
CV5000.exe : The application software for version up
├
2
CLInst.dll : The DLL file for version up
├
3
Topusb.inf : The INF file for USB driver
├
4
TOPUSB.sys : The SYS file for USB driver
├
5
USB_DAM.dll : The DLL file for USB driver
├
6
CVPSV###.rom : The ROM software to be newly released for the CV power supply unit (Ver. 1.11 or higher)
└
7
V###.rom : The ROM software to be newly released for CV-5000 (Ver. 1.13 or higher)
R-CV5000-0-0704-01
