− 47 −
3-6-5 Cornea position adjustment
Illustration
Procedure
1. Turn on the power and open the window of each lens.
2. Insert the cornea scale position adjustment tool into the opened window until it stops.
3. Loosen the fixing screw and align the scale with the cornea vertex position.
Caution: When replacing the spherical lens unit, the cornea position has already been adjusted
when shipped from the factory.
Cornea scale position adjustment tool
