− 20 −
3-4 Names of Motors and Sensors
3-4-1 Names of motors in the spherical lens unit and their arrangement
[Spherical lens unit for left eye]
* Names of motors and their arrangement for right eye are symmetrical to left eye.
Spherical motor No. 2 (S2)
Co
rnea illumination LED
Spherical motor No. 1 (S1)
Spherical motor No. 3 (S3)
Spherical lens zero detection sensor
R-CV5000-0-0704-01
