− 35 −
YES
NO
YES
NO
5
Convergence is done in the zero detection
direction and rattling noise is heard.
Does the convergence unit
reach the limit position?
Replace the MAIN PCB.
)
There is voltage of +5V
between TP1 and GND.
Replace the convergence limit
sensor.
R-CV5000-0-0704-01
