Topcon GPT-3000 Series User Manual

9-16
9 MEMORY MANAGER MODE
9.7.3 Setting Parameter of Data Communications
● Items of the Parameter
● Example Setting Baud rate : 19200
Item Selecting Item Contents
F1: Protocol
[ACK/NAK],
[ONE WAY]
Setting Protocol
[ACK/NAK] or [ONE WAY] communication
F2: Baud rate
1200, 2400, 4800,
9600, 19200, 38400
Setting transfer speed
1200/2400/4800/9600/19200/38400 baud
F3: Char. / Parity
[7/EVEN], [7/ODD],
[8/NON]
Setting data length and parity.
[7bit, even], [7bit, odd], [8bit,none]
F1: Stop Bits 1, 2 Setting Stop 1 bit or 2bits
Operating procedure Operation Display
1
Press the [F3](MEMORY MGR.) key from the
menu 1/3.
[F3]
2
Press the [F4](P
↓
) key twice.
[F4]
[F4]
3
Press the [F1](DATA TRANSFER) key .
[F1]
4
Press the [F1](GTS FORMAT) key .
[F1]
5
Press the [F3](COMM. PARAMETERS) key.
[F3]
6
Press the [F2](BAUD RATE) key.
[ ] indicates present setting.
[F2]
7
Select the items by pressing []or[] , []
and [ ] keys. *1)
[]
[]
8
Press the [F4](ENTER) key.
[F4]
*1) To cancel setting, press the [ESC] key.
MEMORY MGR. 1/3
F1:FILE STATUS
F2:SEARCH
F3:FILE MAINTAN P
↓
MEMORY MGR. 3/3
F1:DATA TRANSFER
F2:INITIALIZE
P
↓
DATA TRANSFER
F1:GTS FORMAT
F2:SSS FORMAT
DATA TRANSFER
F1:SEND DATA
F2:LOAD DATA
F3:COMM. PARAMETERS
COMM. PARAMETERS 1/2
F1:PROTOCOL
F2:BAUD RATE
F3:CHAR./PARITY P
↓
BAUD RATE
[1200] 2400 4800
9600 19200 38400
ENTER
BAUD RATE
1200 2400 4800
9600 [19200]38400
ENTER
COMM. PARAMETERS 1/2
F1:PROTOCOL
F2:BAUD RATE
F3:CHAR./PARITY P
↓
