2-1

2 PREPARATION FOR MEASUREMENT

2.1 Power Connection

(unnecessary if on-board Ni-MH battery BT-52QA is used)

See below for connecting the external battery pack.

● Battery pack BT-3Q

Power cord , PC-5 is used.

● Large capacity battery pack BT-3L

Power cord PC-6 is used.

Connector ends

PC-5

PC-6

PC-5

PC-6

BT-3Q

BT-3L

Note: BT-32Q on-board (Ni-Cd) battery can be also available.

To use BT-32Q (Ni-Cd) battery, it is required to change battery type in selecting mode, see

Section 6.4.5 “Selecting Battery Type”.

Cable

Battery pack
