7-13

7 DATA COLLECTION

Press the [F1](INPUT) key and enter Forward

direction offset value. *1)

[F1]

Enter HD

[F4]

Collimate the prism.

Collimate P

Press the [F2] or [F3] key.

Example:[F3](NEZ) key

Measuring starts.

The data is recorded and the next measuring point

is displayed.

[F3]

*1) To skip entering, press the [F3](SKP) key.

PT# :PT-11

PCODE : TOPCON

R.HT : 1.200 m

––– *SD NEZ NP/P

N*[n] <<< m

E : m

Z : m

>measuring ...

>Calculating...

PT#

→

PT-12

PCODE :TOPCON

R.HT : 1.200 m

INPUT SRCH MEAS ALL
