Topcon IS-100 - Unit Dimensions

OPHTHALMIC UNIT
IS-100
Rev. 6 - November 2019Rev. 6 - November 2019
3-4
USER MANUAL
3.1.3. Unit dimensions
Figure 3-2 shows the dimensions of the unit, and also the maximum and
minimum heights the chair can reach.
2025
865
385
1080
1470
880
Min: 430 / Max: 630
Figure 3-2. Dimensions of the unit.
