OPHTHALMIC UNIT
IS-100
Rev. 6 - November 2019
3-1
Rev. 6 - November 2019
USER MANUAL USER MANUAL
3. DESCRIPTION OF THE UNIT
The unit is designed to facilitate support and positioning of ophthalmic
instruments used during examination and diagnosis of patients. To do this, it has
electronically regulated power contacts and patient seating using an electric
lifting group.
The Figure 3-1 shows the components of the unit.
1
Ophthalmic unit.
See Section 3.2.1.
2
Ophthalmology chair.
See Section 3.3.
3
Phoropter arm (optional).
4
Lens drawer (optional).
See Section 3.4.
5
Support CV5000 PS (optional).
6
Near vision lamp (optional).
3
1
2
4
6
4
5
Figure 3-1. Components of the unit.
