OPHTHALMIC UNIT
IS-100
Rev. 6 - November 2019Rev. 6 - November 2019
3-6
USER MANUAL USER MANUAL
3.3. OPHTHALMOLOGY CHAIR
The ophthalmology chair (Figure 3-4) has a variety of amenities for the comfort
of the patient, listed below.
1
Chair.
2
Armrest.
3
Footrest (optional).
4
Hand manual.
5
Lifting column.
1
3
4
2
5
Figure 3-4. Ophthalmology chair.
The chair (1) has a vertical lifting group (5) to adjust its height, this adjustment is
done using the keyboard. See Section 4.2.1.
It also has a hand brake (4) to lock and unlock its rotation.
