OPHTHALMIC UNIT
IS-100
Rev. 6 - November 2019Rev. 6 - November 2019
4-3
USER MANUAL
4.2.2. Phoropter arm (Optional)
Thephoropterarm(Figure4-1)hasdierentregulationsthatallowadjustingthe
position of the phoropter accurately to the patient’s face. Table 4-1 lists possible
adjustments the phoropter has and also the procedure on how to carry them out.
5
6
1
2
3
4
7
Figure 4-2. Adjustment of the phoropter arm.
