25
Slim Line - Application Illustrations
C = 2-5/8"
4-11/16"
Inswing 0” - 6” Reveal
1-1/2"
C = 2-5/8"
Inswing 0” Reveal
14-1/4” [362]
CL
Hinge
1
2
Operator Header
Wall
12-3/16” [310]
12-3/16” [310]
5/8” [16]
4”
[102]
Operator Header
C/L
Pivot
Butt Hingle or Offset Pivot
C/L
Shaft
10-5/8” [270]
Butt Hinge
2-1/4”
[57]
C/L
Pivot
Operator Header
C/L
Shaft
1-1/4”
[32]
C/L
Pivot
Operator Header
9-7/16”
[240]
Center Pivot
C/L
Shaft
C = 7/8"
2"
1-3/16"
Outswing
14 - 15 lbs. Spring Holding Force
14-1/4” [362]
CL
Hinge
3
May require cutting the
arm to shorten the length.
Operator Header
Wall
Reference 1102/ 1201 Installation and
Operating manual for commissioning
and programming instructions for
specific applications listed.
1-5/8”"
REVISIONS
DEVOR
PPAETADNOITPI
RCSED.
V
ER
HM6102/72/4eus
sI
tsri
FA
Drawing Number \ Revision
1102 / 1201
Slim Line Swing Door
Applications
Description:
SHEET 2 OF 2
1102-1201 Header Fabrication Sheet
:e
t
aD:yB nwarD
Mario Higuera 5/11/2016
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
TORMAX USA. ANY REPRODUCTION IN
PART OR AS A WHOLE WITHOUT THE
WRITTEN PERMISSION OF TORMAX USA
IS PROHIBITED.
Tormax USA, Inc.
10-5/8” [270]
Inswing 0 - 6” Reveal - Butt Hinge
2-1/4”
[57]
C/L
Pivot
Header
C/L
Shaft
12-3/16” [310]
Header
C/L
Pivot
C/L
Shaft
16-1/8” [409]
C/L
Door
Portion
Arm
Door
Outswing 14 - 15 lbs. Spring Holding Force
C = 2-5/8"
4-11/16"
Double Egress Pair
1-1/2"
Inswing
Door
Door
Door
Commissioning and
programming page 14.
Commissioning and
programming page 12.
Commissioning and
programming page 16.
Commissioning and
programming page 18.
Application Wiring page 20, commissioning and
programming page 21.
C/L Bottom
mounting hole
C/L Bottom
mounting hole
C/L Bottom
mounting hole
C/L Bottom
mounting hole
C= 2-5/8”
1-3/4"
8 - 10 lbs. Spring Holding Force
16-1/8” [410]
CL
Hinge
12-3/16” [310]
Wall
Operator Header
Leave shaft mounting
bolt loose in the operator.
To Next Page
