4 Instructions for Use iMotion 2202 / 2301/ 2302 / 2401 T-1321 e
<
1.4 Explanation of the Symbols
Warning (signal word)
Source of hazard (designates a possibly hazardous situation)
Possible consequences of non-observance
•Measuresforavertingdanger.
Text which is highlighted in grey MUST be observed to ensure that the system operates perfectly.
Failure to observe these sections can cause damage to equipment.
Functions marked with this symbol are the factory setting. However, they can be reprogrammed
by a specialist.
Optional components which are not present in all systems.
1.5 Technical Data
Drive type Electro-mechanical sliding door drive with direct drive (iMotion 2301,
2302, 2401) using an AC permanent magnet synchronous motor
Control system Control unit MCU32
Mains connection 1 x 230 VAC, 50 – 60 Hz, 10 A / 1 x 115 VAC, 50 – 60 Hz, 15 A
Power consumption iMotion 2202, 2301, 2302: max. 190 W
iMotion 2301.IP65: max. 240 W
iMotion 2401: max. 310 W
iMotion 2401.IP65: max. 350 W
Sensor supply iMotion 2202, 2301, 2302: 24 V DC (+0,5 –1,5 V) 0,75 A
in battery operation min. 16,5 V
iMotion 2401: 24 V DC (+0,5 –1,5 V) 1,5 A
in battery operation min. 16,5 V
iMotion 2301.IP65: 0,75 A
iMotion 2401.IP65: 1,5 A to +30 °C, 1,0 A to +50 °C
Protective class, drive IP 22 ( IP65 for iMotion 2301.IP65 and 2401.IP65)
Fusible 5 AT
Ambient temperature –20 °C to +50 °C
Noise emission level < 70 db (A)
