2 Instructions for Use iMotion 2202 / 2301/ 2302 / 2401 T-1321 e
First edition: 10.08, Update: 3.11, 2.12, 12.13
We reserve the right to make technical changes.
Printed on environmentally friendly paper bleached without the use of chlorine.
Landert Motoren AG and Landert GmbH are certified to ISO 9001.
Contents
1 General Information 3
1.1 Target Groups 3
1.2 Storage and dissemination of the manual 3
1.3 Area of Application 3
1.4 Explanation of the Symbols 4
1.5 Technical Data 4
2 Safety 5
2.1 Responsibilities 5
2.2 Use for the Purpose Intended 5
2.3 Pre-conditions for the Operation of the System 5
2.4 Hazards and Risks 5
2.5 Checks 6
2.6 Taking the System out of Service in the Event of a Fault 6
2.7 Disposal 7
3 Product Description 8
3.1 System Overview 8
3.2 System Function 9
3.3 Operating Modes 10
4 Operation 11
4.1 Commissioning 11
4.2 Operation with the TORMAX User Interface 11
4.3 Operation with an Operating Mode Switch 12
4.4 Operation on Power Failure 12
5 Procedure in the Event of a Fault 13
6 Maintenance 14
6.1 Cleaning 14
6.2 Functional Checks 14
6.3 Maintenance and Testing 14
7 Appendix 15
7.1 Fault Table 15
7.2 Check-list for Functional Checks 17
Declaration of Conformity 18
