Tornado 99328 User Manual

29
SQUEEGEE PIVOT FRAME PARTS LIST
(Ref. Drawing 31184)
ITEM QTY PART # DESCRIPTION
1 1 00067 NUT - LOCK 5/16-18
2 1 01589 NUT - FINISHED HEX 5/16-18
3 2 03321 WASHER - PLAIN .391
4 1 03418 KNOB, HANDLE
5 18 03736 WASHER - PLAIN 3/8
6 1 03931 WASHER - PLAIN 5/8
7 1 15666 SPACER, SQUEEGEE LIFT
8 1 15677
SCREW-SOCKET HD SHOULDER 3/8D x 3/8
9 1 15684 LEVER, SQUEEGEE LIFT
10 1 15869
SCREW - SOCKET HD SHOULDER 3/8D x 1.00
11 1 16069 SCREW - FLAT HEAD SOCKET CAP
12 5 16254
COTTER PIN 1/8 x 1.00
13 6 16255
COTTER PIN 1/16 x 3/4
14 10 16347 BEARING
15 2 16354 ROCKER
16 3 16361 PIN
17 1 16367 SPRING - EXTENSION
18 1 16464 SPRING - EXTENSION
19 1 16687 GROMMET
20 1 16689 NUT - HEX LOCK (NYLON INSERT) 5/8-18
21 3 16796 SPACER
22 1 16844 PIVOT FRAME WELDMENT
23 1 16850 R.H. ARM WELDMENT
24 1 16851 L.H. ARM WELDMENT
25 1 16852 CATCH WELDMENT
26 1 16855 BRACKET - RIGHT HAND
27 1 16856 L.H. BRACKET WELDMENT
28 2 16858 PIN, PIVOT
29 2 16859 PIN, PIVOT
30 1 16861 SPACER
31 1 16863 PIVOT BRACKET WELDMENT
32 1 16869 SPACER
33 1 16915 SQUEEGEE LINK
34 1 17287 PIVOT FRAME WELDMENT
35 1 31187 PIN, PIVOT
